ESRF (European Synchrotron Radiation Facility) hired ASE Optics Europe to design and manufacture three unique objective lenses for use in the synchrotron beamlines: 0.5X, 150mm and 400mm. Starting with a Discovery Service, ASE designed and developed the optical system consisting of thorough optical tolerance analysis, mechanical design and finally manufacturing and quality control.

The optical system was designed using a judicious choice of materials to reach all requirements. The system required expert alignment and testing: ASE EU developed an in-house MTF measuring station based on knife-edge technique.
